Vintage Sansui 790 // Solid-State Receiver / Professionally Serviced / Rare

The Sansui 790 is a rare european variant of the classic 7070 receiver. We've fully serviced this unit, but there wasn't much for us to do. This piece is in excellent condition.

RESTORATIONS

• Full 30-point service check
• Rewired antenna
• Installed LEDs
• Burnished relay contacts
• Cleaned controls, switches, and chassis

SPECS

Type   Solid-state AM.FM stereo receiver

Tuning range   AM/FM

Power output   60 watts per channel into 8Ω (stereo)

Frequency response   20Hz to 30kHz

Total harmonic distortion   0.3%

Damping factor   45

Input sensitivity   2.5mV (mic), 2.5mV (MM), 150mV (line)

Signal to noise ratio   70dB (MM), 80dB (line)

Channel separation   50dB (MM), 50dB (line)

Output   150mV (line), 30mV (DIN)

Speaker load impedance   4Ω to 8Ω

Dimensions   19.75"W x 6.14"H x 14.61"D

Weight   36.6 lbs.

LINER NOTES

The Sansui 790 is an advanced electronic design in the medium-power/medium-price range. It has 65 watts, both channels driven into 8 ohms at 1000Hz, giving you adequate power to drive two sets of full-size speaker systems. Features include a highly sensitive MOS FET FM front-end and a Dolby FM adaptor terminal.
